CS2000

CS2000 Specifications:

• 2 discreet isolated output channels
• Non volatile memory for treatment program parameter storage
• (4) Preprogrammed treatment programs: Inflammation, FMS, DOMS, Wound healing
• Treatment Programs (per channel): 16
• Treatment Program Steps: 1 to 16
• Treatment Program Step resolution: 1 second (provides frequency sweep capability)
• Treatment Program Repeat Sequence: 1 to 4 (Repeats or loops Step xx to Step xx for xx Minutes)
• Treatment Program total minutes remaining count down timer
• Step count down timer: 1 to 60 seconds
• Frequency: 0.01 to 999.99 Hz. Accuracy: 0.05%
• Intensity: 0 to 600 uA. Accuracy: +/- 1uA, 10 uA steps
• Polarity: Biphasic, positive and negative monophasic
• 4 x 40 character LCD display
• 5 tactile push button keys for editing parameters and system functions.
• 2 ultra bright LEDs per channel: Indicate electrode contact, frequency, polarity, Treat / Stop
• Output Voltage: +/- 37 V
• Waveform: Patent Pending Biphasic modified square non-constant current with exponential pulse avalanche
• Anti-Acclimatizing: Unique Auto waveform frequency switching
• Enclosure Dimensions: 11.5 x 8 x 3″
• Weight: 1.0 lbs.
